XP 100
XP 100
Product Overview
XP100 is a premium passenger elevator that fully embodies the flagship engineering philosophy of the Bronze Lift XP Series. It is designed to deliver reliable performance, refined ride comfort, and long-term operational continuity even under the most demanding operating conditions.
The platform supports a wide range of applications, including passenger, service, and firefighter use. High traffic intensity, continuous operation, and heavy cabin scenarios are integral to XP100’s natural operating scope.
With extensive design freedom—covering metal, wood, glass, natural stone, and bespoke finishes—XP100 enables architectural expression without limitation and stands as the reference model of the XP Series, ready for diverse markets and regulatory environments.
Technical Specifications
Product_TechSpecs_Desc
| Rated load (Q) | ((kg)) | 450 |
|---|---|---|
| Speed (v) | ((m/s)) | 1.0 |
| Max. travel height (TH) | (m) | 40 |
| Number of passengers | 6 | |
| Double entrance | Yes/No | |
| Max. number of stops | 16 | |
| Car width CW | (mm) | 1000 |
| Car depth CD | (mm) | 1250 |
| Car height | (mm) | 2100 - 2700 |
| Max. weight of car | ((kg)) | 800 |
| Door width DW | (mm) | 800 |
| Door height DH | (mm) | 2000-2300 |
| Min Shaft width SW (2P Side Opening) (2P Side Opening) |
(mm) | 1500 |
| Min Shaft width SW (2P Central Opening) (2P Central Opening) |
(mm) | 1800 |
| Min Shaft depth SD-door in shaft (2P Side Opening) (2P Side Opening) |
(mm) | 1500 |
| Min Shaft depth SD-door in recess (2P Side Opening) | (mm) | 1470 |
| Min Shaft depth SD-door in shaft (2P Central Opening) | (mm) | 1500 |
Product Features
Engineering Authority
Heavy-Duty Readiness
Unlimited Design Freedom
